Lenovo ThinkPad Ultra Docking Station - Docking station - VGA, HDMI, 2 x DP - 135 Watt - Korea, Europe - for ThinkPad L14 Gen 1; L15 Gen 1; P14s Gen 1; P15s Gen 1; X1 Carbon Gen 8; X13 Gen 1
1 of 3
Lenovo ThinkPad Ultra Docking Station - Docking station - VGA, HDMI, 2 x DP - 135 Watt - Korea, Europe - for ThinkPad L14 Gen 1; L15 Gen 1; P14s Gen 1; P15s Gen 1; X1 Carbon Gen 8; X13 Gen 1
- Innovative side connection, exclusively for ThinkPad notebooks
- Designed with Enterprise IT in mind
- Upgraded performance
Frequently bought together
Product Specification
- Product Code
- 4645046
- Manufacturer Ref
- 40AJ0135EU
- Barcode
- 192076019854
- Type
- Check Specifications DO NOT USE
- Brand
- Lenovo
- Number of USB-A Ports
- 4
- Number of USB-C Ports
- 2
- HDMI
- Yes
- VGA
- Yes
- DisplayPort
- Yes
- Network Port
- Yes
- Power Delivery
- No
- Headphones Port
- Yes
- Card Reader
- No
- Thunderbolt
- No
Product Details
- Lenovo ThinkPad Ultra Docking Station - Docking station - VGA, HDMI, 2 x DP - 135 Watt - Korea, Europe - for ThinkPad L14 Gen 1; L15 Gen 1; P14s Gen 1; P15s Gen 1; X1 Carbon Gen 8; X13 Gen 1
ThinkPad Docking Stations provide the best docking experience for large enterprise ThinkPad customers. The innovative side connector, designed exclusively for ThinkPad laptops, provides a driver-free way to connect conveniently and securely to a range of USB accessories and external displays, while rapid charging support and a mirrored power button make it easy to pack and go. Designed for large enterprise environments, ThinkPad Docking Stations support PXE boot, wake on LAN, and MAC address pass-through, simplifying asset management for IT managers. Painstakingly designed extensively tested, ThinkPad Docking Stations provide a seamless docking experience.
Specifications
| General | |
|---|---|
| Product Type | Docking station |
| Width | 37.8 cm |
| Depth | 15.9 cm |
| Height | 5.41 cm |
| Weight | 810 g |
| Localisation | Korea, Europe |
| Video | |
| Max Resolution Details | 4096 x 2160 - 60 Hz (DisplayPort only) ¦ 4096 x 2160 - 60 Hz (HDMI only) ¦ 2048 x 1536 - 85 Hz (VGA only) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort1 and DisplayPort2 simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (DisplayPort and VGA simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (HDMI and VGA simultaneously) ¦ 4096 x 2160@60Hz, 1920 x 1080@60Hz, 1920 x 1080@60Hz (DisplayPort1 and DisplayPort2 and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz, 2048 x 1536@85Hz (DisplayPort and HDMI and VGA simultaneously) |
| Expansion / Connectivity | |
| Interfaces | 1 x USB 3.1 Gen 2 with Always-on charging ¦ 3 x USB 3.1 Gen 2 ¦ 2 x USB-C ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x audio - headphones/microphone - mini-phone stereo 3.5 mm ¦ 1 x docking / port replicator |
| Miscellaneous | |
| Included Accessories | 2 x security keys |
| Features | Security lock slot (cable lock sold separately), wake on LAN, Preboot Execution Environment (PXE) support, MAC address pass-through |
| Compliant Standards | UL, cUL, NOM, FCC, ICES |
| Power | |
| Power Device | Power adapter |
| Power Provided | 135 Watt |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 42.2 cm |
| Shipping Depth | 20 cm |
| Shipping Height | 8.6 cm |
| Shipping Weight | 2 kg |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
| Compatibility Information | |
| Designed For | Lenovo ThinkPad A285 20MW, 20MX ¦ Lenovo ThinkPad A485 20MU, 20MV ¦ Lenovo ThinkPad L13 20R3, 20R4 ¦ Lenovo ThinkPad L13 Yoga 20R5, 20R6 ¦ Lenovo ThinkPad L14 Gen 1 20U1, 20U2, 20U5, 20U6 ¦ Lenovo ThinkPad L15 Gen 1 20U3, 20U4, 20U7, 20U8 ¦ Lenovo ThinkPad L480 20LS, 20LT ¦ Lenovo ThinkPad L490 20Q5, 20Q6 ¦ Lenovo ThinkPad L580 20LW, 20LX ¦ Lenovo ThinkPad L590 20Q7, 20Q8 ¦ Lenovo ThinkPad P14s Gen 1 20S4, 20S5, 20Y1 ¦ Lenovo ThinkPad P15s Gen 1 20T4, 20T5 ¦ Lenovo ThinkPad P43s 20RH, 20RJ ¦ Lenovo ThinkPad P52s 20LB, 20LC ¦ Lenovo ThinkPad P53s 20N6, 20N7 ¦ Lenovo ThinkPad T14 Gen 1 20S0, 20S1, 20S2, 20S3, 20UD, 20UE ¦ Lenovo ThinkPad T14s Gen 1 20T0, 20T1, 20UH, 20UJ ¦ Lenovo ThinkPad T15 Gen 1 20S6, 20S7 ¦ Lenovo ThinkPad T480 20L5, 20L6 ¦ Lenovo ThinkPad T480s 20L7, 20L8 ¦ Lenovo ThinkPad T490 20N2, 20N3, 20Q9, 20QH, 20RX, 20RY ¦ Lenovo ThinkPad T490s 20NX, 20NY ¦ Lenovo ThinkPad T495 20NJ, 20NK ¦ Lenovo ThinkPad T495s 20QJ, 20QK ¦ Lenovo ThinkPad T580 20L9, 20LA ¦ Lenovo ThinkPad T590 20N4, 20N5 ¦ Lenovo ThinkPad X1 Carbon (6th Gen) 20KG, 20KH ¦ Lenovo ThinkPad X1 Carbon (7th Gen) 20QD, 20QE, 20R1, 20R2 ¦ Lenovo ThinkPad X1 Carbon Gen 8 20U9, 20UA ¦ Lenovo ThinkPad X1 Yoga (4th Gen) 20QF, 20QG, 20SA, 20SB ¦ Lenovo ThinkPad X1 Yoga Gen 5 20UB, 20UC ¦ Lenovo ThinkPad X13 Gen 1 20T2, 20T3, 20UF, 20UG ¦ Lenovo ThinkPad X13 Yoga Gen 1 20SX, 20SY ¦ Lenovo ThinkPad X280 20KE, 20KF ¦ Lenovo ThinkPad X390 20Q0, 20Q1, 20SC, 20SD ¦ Lenovo ThinkPad X390 Yoga 20NN, 20NQ ¦ Lenovo ThinkPad X395 20NL, 20NM |
