Zyxel GS1920-24HPv2 - Switch - smart - 24 x 10/100/1000 (PoE+) + 4 x combo Gigabit SFP + 4 x 10/100/1000 - rack-mountable - PoE+ (375 W)
1 of 4
Zyxel GS1920-24HPv2 - Switch - smart - 24 x 10/100/1000 (PoE+) + 4 x combo Gigabit SFP + 4 x 10/100/1000 - rack-mountable - PoE+ (375 W)
- Whisper-quiet operation
- User-friendly LED indicators
Frequently bought together
Product Specification
- Product Code
- H44276942
- Manufacturer Ref
- GS192024HPV2-GB0101F
- No of Ports
- 24 Ports
- Brand
- ZyXEL
Product Details
- Zyxel GS1920-24HPv2 - Switch - smart - 24 x 10/100/1000 (PoE+) + 4 x combo Gigabit SFP + 4 x 10/100/1000 - rack-mountable - PoE+ (375 W)
The GS1920 series is ideal for SMB deployment in multiple scenarios, with its unique port combinations future proofing your network to ensure easy growth down the road.
- Whisper-quiet operation
Smart fan and fanless designs for silent operation in your workplace. - User-friendly LED indicators
View real-time status instantly with cloud and PoE power-usage LED indicators.
Specifications
| General | |
|---|---|
| Device Type | Switch - 24 ports - smart |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE+) + 4 x combo Gigabit SFP + 4 x 10/100/1000 |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 375 W |
| Performance | Switching capacity: 56 Gbps ¦ Forwarding rate: 42 Mpps |
| Capacity | QoS hardware queues per port: 8 |
| MAC Address Table Size | 16K entries |
| Routing Protocol | IGMPv2, IGMP, IGMPv3 |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS, TACACS+ |
| Features | Flow control, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, MAC address filtering, Broadcast Storm Control, IPv6 support, IP address filtering, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Weighted Fair Queuing (WFQ), ZyXEL iStacking Technology, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Quality of Service (QoS), RADIUS support, MLD snooping, DHCP relay, Port Security, SNMP trap, DHCP client, Management Information Base (MIB), Multicast VLAN Registration (MVR), Dynamic VLAN Support (GVRP), dual firmware images, Strict Priority Queuing (SPQ), Neighbor Discovery Protocol (NDP), port isolation, Class of Service (CoS), IGMP proxy, 802.1x authentication, Duplicated Address Detection, cloud managed, DiffServ Code Point (DSCP) support, 1.5MB packet buffer, ErrDisable Recovery, IGMP filtering, IGMP throttling, Protocol-based VLANs support, CPU protection, IP source guard, ARP inspection, Internet Control Message Protocol (ICMP), VLAN filtering, Loop Guard, Voice VLAN, Private VLAN, Guest VLAN, Weighted Round Robin (WRR), MAC based VLAN, VLAN Tagging, port-based VLAN, Unknown Storm Control, MRSTP, MAC freeze |
| Compliant Standards | IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
| RAM | 256 MB |
| Flash Memory | 32 MB |
| Expansion / Connectivity | |
| Interfaces | 24 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 4 x 1000Base-X SFP ¦ 4 x 1000Base-T RJ-45 |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 463.5 Watt |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| MTBF | 638,691 hours |
| Compliant Standards | BSMI, RoHS, FCC Part 15 A, LVD, EMC Class A |
| Localisation | United Kingdom |
| Dimensions & Weight | |
| Width | 44.1 cm |
| Depth | 27 cm |
| Height | 4.4 cm |
| Weight | 3.8 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 61.6 cm |
| Shipping Depth | 35.5 cm |
| Shipping Height | 10.7 cm |
| Shipping Weight | 4.97 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 95% (non-condensing) |
